L7-T1 airport intelligent bird repelling robot

L7-T1 airport intelligent bird repelling robot IR-IM1003

The IR-IM1003 airport intelligent bird repelling robot system is equipped with multiple acquisition and detection modules, which can achieve autonomous navigation and inspection in complex terrains, and perform real-time monitoring, data analysis and management of the inspection area. It has functions such as intelligent control, autonomous charging, sound wave bird repelling, and intelligent pest control. At the same time, the robot inspection system is not affected by adverse weather conditions and can achieve uninterrupted bird repelling operations 24/7, greatly improving bird repelling efficiency and safety, providing a solid and reliable guarantee for the safe operation of airports.

SHENGHAO

Super athletic ability
The unique track type differential drive mechanism can achieve flexible steering and adapt to complex airport terrain, and can rotate 360 ° in place.
Accurate positioning navigation
The robot uses "RTK differential positioning+3D radar navigation" as its core to build a precise autonomous movement system and achieve centimeter level positioning.
All-around bird repelling
The directional sound wave bird repellent is equipped with a dedicated frequency sound wave library for common dangerous birds in airports, and accurately drives them away through "acoustic deterrence"; The UV mobile insect killing lamp is equipped with a high-voltage power grid to reduce the number of insects and cut off the food source for birds;
Long endurance and strong adaptability
-In an environment ranging from 20 ℃ to 50 ℃, the built-in battery temperature control system ensures stable operation, with a battery life of up to 8 hours, truly achieving all-weather and all terrain operation, eliminating the limitations of artificial weather and terrain.

Main functions

Acoustic bird repelling
Mobile pest control
Collecting bird emotions
autonomous inspection
self-charging
Flexible steering

Technical Parameters

Dimensions Navigation and positioning method endurance Fastest horizontal movement speed Bird repelling methods Pest control methods: 1100×780×1160mm RTK+3D LiDAR+Inertial Navigation 8h 1.0m/s Acoustic bird repellent, effectively dispersing birds over a distance of more than 100 meters, Light lure, high-pressure killing, frequency vibration insect extermination

Super athletic ability

The unique track type differential drive mechanism can achieve flexible steering and adapt to complex airport terrain, and can rotate 360 ° in place.

Accurate positioning navigation

The robot uses "RTK differential positioning+3D radar navigation" as its core to build a precise autonomous movement system and achieve centimeter level positioning.

All-around bird repelling

Long endurance and strong adaptability

-In an environment ranging from 20 ℃ to 50 ℃, the built-in battery temperature control system ensures stable operation, with a battery life of up to 8 hours, truly achieving all-weather and all terrain operation, eliminating the limitations of artificial weather and terrain. ​

-In an environment ranging from 20 ℃ to 50 ℃, the built-in battery temperature control system ensures stable operation, with a battery life of up to 8 hours, truly achieving all-weather and all terrain operation, eliminating the limitations of artificial weather and terrain.
